At Serviacero Comercial we are manufacturers of losacero 25 sheet, in galvanized finish, from 18 to 24 gauge, we can make lengths according to the size of your project from 2.00 to 12.20 m, it is used for the production of mezzanines and ceilings, it is a material easy to install and durable.
At Serviacero Comercial we manufacture losacero 25 sheet in galvanized finish, in caliber 18, 20, 22 and 24, we make lengths according to your project from 2.00 to 12.20 m and with an effective width of 91.5 cm, under the highest quality standards, it is Made of grade 37 structural steel offering a system with excellent structural resistance.
Losacero 25 sheet is ideal for the construction and structural industry and can be found in a wide variety of applications.
1. Resistance: it is a material designed to withstand large loads which makes it ideal for projects such as warehouses and buildings.
2. Easy installation: it is a light material, but without losing the property of resistance, also because its lengths are made to measure, it is easy to install and place and this represents savings in labor costs.
3. Durability: it is made of high-resistance steel and a galvanized finish, these characteristics make it a durable material in the face of climatic conditions.
4. Insulation: offers a certain level of acoustic and thermal insulation, improving environmental conditions within the construction.
5. Compatibility: it can be combined not only with steel materials but with concrete, masonry, among others.
6. Environmentally friendly: being made of steel, it is a 100% recyclable material.
• Construction: for the production of ceilings and mezzanines in warehouses, warehouses, shopping centers, hospitals, hotels, airports, offices, buildings, warehouses, industrial plants.
• Road infrastructure: used in the construction of bridges and walkways, providing resistant and efficient structural support.
• Sports venues: can be used for the construction of gyms, stadiums and sports venues.
• Agricultural: it is used for the production of roofs and mezzanines of different farms, stables, sheds and animal care facilities thanks to its characteristics.
Losacero sheet is used for countless projects thanks to its physical and mechanical properties, simplifying construction and offering a reliable solution for a variety of applications.
| Tabla de Pesos Teóricos de Servicio Losacero 25 | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Calibre | ESP. ACERO BASE | Peso | Compresión Superior m+ | Compresión Inferior M- | Cortante adm. | ANCHO EFECTIVO | ||||||
| Ixe + | Sxe+ | M axo+ | Ixe - | Sxe- | Maxo - | Vay (kg/Mto.Ancho) | ||||||
| mm | Pulg. | kg/ml | kg/m2 | cm4/m | cm3/m | Kg-m | cm4/m | cm3/m | kg-m | |||
| 24 | 0.607 | 0.0239 | rec | 6.04 | 51.07 | 13.01 | 203 | 51.07 | 13.75 | 214 | 1397 | 0.93 |
| 22 | 0.759 | 0.0299 | 7.6 | 8.31 | 67.48 | 18.01 | 281 | 67.03 | 18.82 | 293 | 2206 | 0.93 |
| 20 | 0.912 | 0.0359 | 9.06 | 9.9 | 88.46 | 23.14 | 361 | 83.46 | 24.08 | 375 | 3181 | 0.93 |
| 18 | 1.214 | 0.0478 | 11.96 | 13.07 | 111.32 | 32.76 | 511 | 111.32 | 34.13 | 532 | 4213 | 0.93 |
| Manejamos medidas especiales sobre pedido | ||||||||||||
| Servicio Losacero 25 - CONCRETO NORMAL, F´C0=2200 KG/CM2, P. VOL. 2400 KG/M3: N=10 | |||||
|---|---|---|---|---|---|
| Calibre | Esp. De Concreto | Peso Propio | CLARO MÁXIMO SIN APUNTALAR | ||
| Esp de Diseño | SIMPLE | DOBLE | TRIPLE | ||
| PLG. | cm | kg/m2 | m | m | m |
| 24 0.0239 | 5 | 195 | 1.77 | 2.38 | 2.41 |
| 6 | 218 | 1.7 | 2.29 | 2.32 | |
| 8 | 264 | 1.59 | 2.15 | 2.17 | |
| 10 | 310 | 1.5 | 2.03 | 2.05 | |
| 12 | 356 | 1.42 | 1.93 | 1.95 | |
| 22 0.0299 | 5 | 205 | 2.08 | 2.68 | 2.77 |
| 6 | 229 | 2.00 | 2.58 | 2.66 | |
| 8 | 277 | 1.86 | 2.40 | 2.48 | |
| 10 | 325 | 1.80 | 2.26 | 2.33 | |
| 12 | 373 | 1.78 | 2.13 | 2.20 | |
| 20 0.0359 | 5 | 206 | 2.42 | 3.05 | 3.15 |
| 6 | 230 | 2.32 | 2.93 | 3.03 | |
| 8 | 278 | 2.16 | 2.74 | 2.83 | |
| 10 | 326 | 2.09 | 2.57 | 2.66 | |
| 12 | 374 | 2.06 | 2.44 | 2.52 | |
| 18 0.0478 | 5 | 209 | 2.97 | 3.62 | 3.74 |
| 6 | 233 | 2.85 | 3.48 | 3.60 | |
| 8 | 281 | 2.63 | 325 | 3.36 | |
| 10 | 329 | 2.56 | 3.06 | 3.16 | |
| 12 | 377 | 2.51 | 2.90 | 3.00 | |
| Grado de acero: GR37. | |||||
