Steel plate is a material that we can find in sheet or plate presentation, we can find a wide variety of calibers, thicknesses and measurements. One of its main characteristics is that it is a flat material with a wide thickness. It is commonly used in the construction industry to make bridges, tanks, platforms, among others thanks to its resistance and durability.
Steel plate is a material whose main characteristics are its thickness and large size. We can find a variety of measurements, calibers and can be in sheet or plate. The plates can be manufactured under ASTM A36, A572, A709, A283, A285, A285-C and A516-70 standards.
In summary, the plates are a material that can be used in different sectors where high resistance and support are sought.
Advantages and characteristics of Steel Plate:
These features and advantages make the boards a popular and reliable choice in various industries where certain features and specifications are required to be met.
ASTM A 36, A572, A709, A283, A285, A285-C, A516-70
Steel plate |
||||||||
|---|---|---|---|---|---|---|---|---|
| Standard Specification ASTM A 36, A572, A709, A283, A285, A285-C, A516-70 | ||||||||
| Theoretical Weights Table | ||||||||
| Dimensions | 3/16" | 1/4" | 5/16" | 3/8" | 1/2" | 5/8" | 3/4" | |
| Feet | Meters | 4.8 mm. | 6.4 mm. | 7.9 mm. | 9.5 mm. | 12.7 mm. | 15.9 mm. | 19.1 mm. |
| 3' x 10' | 0.91 x 3.05 | 104 | 139 | 174 | 209 | 279 | 348 | 418 |
| 4' x 10' | 1.22 x 3.05 | 139 | 186 | 232 | 279 | 372 | 464 | 557 |
| 4' x 20' | 1.22 X 6.10 | 279 | 372 | 464 | 557 | 743 | 929 | 1115 |
| 5' x 10' | 1.52 x 3.05 | 174 | 232 | 290 | 348 | 464 | 581 | 697 |
| 5' x 20' | 1.52 x 6.10 | 348 | 464 | 581 | 697 | 929 | 1161 | 1393 |
| 6' x 20' | 1.83 x 6.10 | 418 | 557 | 697 | 836 | 1115 | 1393 | 1672 |
| 8' x 20' | 2.44 x 6.10 | 557 | 743 | 929 | 1115 | 1486 | 1858 | 2229 |
| 10´ X 20´ | 3.04 X 6.10 | 697 | 929 | 1161 | 1393 | 1858 | 2322 | 2786 |
| Kg per m2 | 38.29 | 51.06 | 63.82 | 76.59 | 102.12 | 127.65 | 153.18 | |
| Kg per Ft2 | 3.56 | 4.75 | 5.94 | 7.12 | 9.50 | 11.87 | 14.25 | |
| Theoretical Weights Table | ||||||||
|---|---|---|---|---|---|---|---|---|
| Dimensions | 7/8" | 1" | 1 1/8'' | 11/4" | 11/2" | 1 3/4'' | 2" | |
| Feet | Meters | 22.2 mm. | 25.4 mm. | 28.5 mm | 31.7 mm. | 38.1 mm. | 44.5 mm | 50.8 mm. |
| 3' x 10' | .914 x 3.05 | 488 | 557 | 627 | 697 | 836 | 975 | 1115 |
| 4' x 10' | 1.22 x 3.05 | 650 | 743 | 836 | 929 | 1115 | 1300 | 1486 |
| 5' x 10' | 1.52 x 3.05 | 813 | 929 | 1045 | 1161 | 1393 | 1625 | 1858 |
| 5' x 20' | 1.52 x 6.10 | 1625 | 1858 | 2090 | 2322 | 2786 | 3251 | 3715 |
| 6' x 20' | 1.83 x 6.10 | 1950 | 2229 | 2508 | 2786 | 3344 | 3901 | 4458 |
| 8' x 20' | 2.44 x 6.10 | 2601 | 2972 | 3344 | 3715 | 4458 | 5201 | 5944 |
| 10´ X 20´ | 3.04 X 6.10 | 3251 | 3715 | 4180 | 4644 | 5573 | 6502 | 7430 |
| Kg per m2 | 178.71 | 204.24 | 229.78 | 255.30 | 306.37 | 357.43 | 408.49 | |
| Kg per Ft2 | 16.16 | 18.47 | 20.78 | 23.09 | 27.70 | 32.32 | 36.94 | |
